Cube Reaction Hybrid Race 800Wh 27.5-inch
-
Currently not available
-
Fast delivery!
-
Convenient financing with easyCredit instalment purchase
-
100,000+ satisfied customers
-
Pay only after 30 days further information
| Frame | Superlite aluminium, Gravity Casting Technology, Agile Ride Geometry, Boost148, fully integrated battery, advanced internal cable routing, 1.5-inch headtube, kickstand/mudguard/luggage rack mounting points |
| Frame shape | Mountainbike |
| Material | Aluminium |
| Gender | Unisex |
| Weight | approx. 24.9 kg |
| permissible total weight | 140 kg |
| Fork | RockShox Recon Silver RL Air, tapered, 15x110mm, 120mm (27.5: 100mm) |
| Manufacturer shift group | Sram |
| Rear derailleur | SRAM Eagle 90 drivetrain, 12-speed |
| Number of gears | 1 x 12 |
| Circuit type | Kettenschaltung |
| Crank handle | ACID MTB Hybrid Pro, 38T |
| Cassette | Sram XS-1270, 10-52T |
| Drive type | Kettenantrieb |
| Freewheel/coaster | Freilauf |
| Pedals included in the scope of delivery | ja |
| Impellers | ACID Pro 30, 32/32 spokes, 15x110mm/12x148mm, tubeless-ready |
| Wheel size | 27,5 Zoll |
| Tyres | Schwalbe Smart Sam, Active, 2.6 |
| Motor manufacturer | Bosch |
| Engine | Performance Line CX |
| max. torque | max. 120 Nm |
| Reach | up to 150 km |
| Support for | up to 25 km/h |
| Battery | Bosch 800Wh PowerTube |
| Display | Bosch Purion 200 |
| Brakes | Magura Louise, 4-piston front/4-piston rear, hydraulic disc brake (203) |
| Handlebars | Cube Rise Trail Bar 35 |
| Seat post | Cube Dropper post, handlebar lever, internal cable routing, 31.6 mm |
| Saddle | ACID Sequence 160 |
| Stem | Cube Performance Stem E-MTB 35, FPI-Link |
| Accessories/Miscellaneous | Charger included |
| Rims | CUBE EX25, 32H, Disc, Tubeless Ready |
| Hubs | front: CUBE Engineered By Newmen, 15mm, Boost, Centrelock, rear: CUBE Engineered By Newmen, 12mm, Boost, Centrelock |
With its robust construction and 800 Wh battery, the Reaction Hybrid Race masters all routes with ease. This e-hardtail is also PowerMore-ready, which means it can carry an additional 250 Wh for even more range if required. Its Bosch CX motor with Smart System is responsible for energetic forward support, while the 12-speed Sram Transmission 90 has the right gear for every situation on the go. For maximum riding comfort and first-class control, we have fitted 2.6-inch wide, grippy Schwalbe tyres and a Rockshox Recon Silver air suspension fork. Speaking of control: the hydraulic 4-piston disc brakes provide powerful braking power when required and slow the bike down reliably and safely in all conditions - and a retractable seat post is also included. Do you like travelling off the beaten track? Then let's get going!
The elegance and quality of the Reaction Hybrid are no coincidence, because the frame comes with many clever features. Its 800 Wh PowerTube battery from Bosch, together with the Bosch CX motor, fits safely, cleanly and beautifully into the design. The chassis is also PowerMore-ready, which means that a further 250 Wh can be added if required. The integrated seat clamp and internally routed cables also play into the clean lines. What else? A mount for the chain guide and the option of retrofitting ACID mudguards, a pannier rack and a compatible ACID front light via X-Connect. Last but not least, thanks to our Size Split System, we have the right fit for everyone. Conclusion: Everything you need for maximum riding fun!
This bike arrives (almost) fully assembled. All you have to do is straighten the handlebars and attach the pedals.
More on statutory warranty rights (europa.eu)
Log in
Important safety information for electric bicycles
The safety information forms part of the user manual, which contains all relevant information.
The digital operating instructions can be accessed here www. Cube.eu/downloads.
Reading the safety information does not exempt you from the obligation to read and follow the user manual!
Failure to follow the operating instructions may lead to dangerous riding situations, falls, accidents and damage to property.
General
Failure to use the product as intended may result in the failure of components and materials, posing a risk of accidents and injury:
Observe the restrictions of the specified usage class / bike classification
Do not exceed the permissible total weight (electric bike + rider + payload + trailer, if applicable)
Observe the manufacturer’s specifications regarding the transport of passengers and loads
Tampering with the drive system, in particular tuning, is not permitted
Check the electric bike for any damage before every ride, particularly to the frame, fork, handlebars/stem assembly, drive unit and seat post
Do not use the electric bicycle if any damage is found
Be aware of the increased risk of injury due to potentially high temperatures of individual components (e.g. brakes, drive unit, headlight)
Follow the manufacturer’s instructions regarding the fitting of accessories (bags, locks, child seats, carrier systems, etc.) and the use of a trailer
Please observe the legal regulations applicable in the respective country regarding use on public roads
When transporting the electric bicycle, the instructions provided by the manufacturer, the relevant authorities or the transport company must be followed
Before setting off
Before every journey, check in particular:
that the brakes, steering, suspension and lights are working properly,
that the handlebars, stem, wheels, mudguard and pedals are securely fastened, as well as
tyre pressure
Checking and adjustment must be carried out in accordance with the manufacturer’s specifications.
Handling
Initially familiarise yourself with the handling and braking behaviour, as well as the electric assistance modes and the push assist (if fitted), particularly when carrying different loads, in wet conditions and on loose surfaces
After riding / maintenance
In the event of damage or malfunctions, the electric bicycle must be inspected by a specialist workshop before further use
Have the electric bicycle regularly inspected and serviced by a specialist workshop in accordance with the manufacturer’s specifications to avoid hazards, e.g. due to wear and tear
Observe the specified torques (Nm) when fitting components
Use only batteries and chargers approved by the manufacturer
Follow the manufacturer’s instructions for charging and using the battery, particularly regarding ambient temperature and the location where charging takes place
Only use undamaged and unmodified batteries and chargers
Modifying the components on the electric bike may affect safety and type approval. Contact your specialist dealer before undertaking such work.
Please contact your specialist dealer if you are unable to carry out the described work on your electric bicycle yourself (e.g. making adjustments), if you feel unsure, or if you do not have the correct tools.
Important safety information for bicycles
The safety information forms part of the user manual, which contains all relevant information.
The digital operating instructions can be accessed here www. Cube.eu/downloads.
Reading the safety information does not exempt you from the obligation to read and follow the user manual!
Failure to follow the operating instructions may lead to dangerous riding situations, falls, accidents and damage to property.
General
Failure to use the product as intended may result in the failure of components and materials, posing a risk of accidents and injury:
Observe the restrictions of the specified usage class / bike classification
Do not exceed the permissible total weight (bicycle + rider + load + trailer, if applicable)
Check the bicycle for any damage before every ride, particularly to the frame, fork, handlebars/stem assembly and seat post
Do not use the bicycle if any damage is found
Be aware of the increased risk of injury due to potentially high temperatures of individual components (e.g. brakes, headlights)
Follow the manufacturer’s instructions for fitting accessories (bags, locks, child seats, carrier systems, etc.) and for using a trailer
Please observe the legal regulations applicable in the relevant country regarding use on public roads
When transporting the bicycle, follow the instructions provided by the manufacturer, the relevant authorities or the transport company
Before riding
Before every ride, check in particular:
that the brakes, steering, chassis and lights are working properly,
that the handlebars, stem, wheels, mudguard and pedals are securely fastened, as well as
tyre pressure
Checking and adjustment must be carried out in accordance with the manufacturer’s specifications.
Handling
Familiarise yourself with the vehicle’s handling and braking behaviour, particularly under varying loads, in wet conditions and on loose surfaces
After riding / maintenance
In the event of damage or malfunctions, the bicycle must be inspected by a specialist workshop before further use
Have the bicycle regularly inspected and serviced by a specialist workshop in accordance with the manufacturer’s specifications to avoid hazards, e.g. due to wear and tear
Observe the specified torques (Nm) when fitting components
Contact your specialist dealer if you are unable to carry out the described work on your bicycle yourself (e.g. making adjustments), if you feel unsure or if you do not have the correct tools.
Important safety information for children’s bicycles
The safety information forms part of the user manual, which contains all relevant information.
The digital user manual can be accessed here: www. Cube.eu/downloads.
Reading the safety information does not exempt you from the obligation to read and follow the user manual!
Failure to follow the operating instructions may lead to dangerous riding situations, falls, accidents and damage to property.
General
Use of the bicycle is only permitted under the supervision of a parent or guardian
Failure to use the bicycle as intended may result in the failure of components and materials, posing a risk of accidents and injury:
Observe the restrictions of the specified usage class / bike classification
Do not exceed the permissible total weight (bike + rider + load + trailer, if applicable)
Check the bicycle for any damage before every ride, particularly to the frame, fork, handlebars/stem assembly and seat post
Do not use the bicycle if any damage is found
Be aware of the increased risk of injury due to potentially high temperatures of individual components (e.g. brakes, headlights)
Follow the manufacturer’s instructions for fitting accessories (bags, locks, child seats, carrier systems, etc.) and for using a trailer
Please observe the legal regulations applicable in the respective country regarding use on public roads
When transporting the bicycle, follow the instructions provided by the manufacturer, the relevant authorities or the transport company
Before riding
Before every ride, check in particular:
that the brakes, steering, chassis and lights are working correctly,
that the handlebars, stem, wheels, mudguard and pedals are securely fastened, as well as
tyre pressure
Checking and adjustment must be carried out in accordance with the manufacturer’s specifications.
Handling
Familiarise yourself with the vehicle’s handling and braking behaviour, particularly under varying loads, in wet conditions and on loose surfaces
After riding / maintenance
In the event of damage or malfunctions, the bicycle must be inspected by a specialist workshop before further use
Have the bicycle regularly inspected and serviced by a specialist workshop in accordance with the manufacturer’s specifications to avoid hazards, e.g. due to wear and tear
Observe the specified torques (Nm) when fitting components
Contact your specialist dealer if you are unable to carry out the described work on your bicycle yourself (e.g. making adjustments), if you feel unsure or if you do not have the correct tools
