Mondraker Dusty RR
-
Available immediately, with you in 8 - 10 working days
-
Fast delivery!
-
Convenient financing with easyCredit instalment purchase
-
Purchase on account
-
Pay only after 30 days further information
Dusty RR
Gravel riding on technical terrain. Our seat stays have been designed for unrivalled comfort and provide plenty of confidence, safety and control on technical terrain. The top model DUSTY RR is also equipped with a RockShox RUDY suspension fork with 40mm travel and the Rockshox Reverb XPLR AXS dropper post with 75mm travel. So when logical thinking says this is the end of the line for a gravel bike, the fun really begins with the DUSTY.
The hub motor delivers 23 Newton metres directly to the rear wheel. If you compare this with a mid-motor that is otherwise often used, it delivers roughly the same power as a motor with 55 Newton metres.
This bike arrives (almost) fully assembled. All you have to do is straighten the handlebars and attach the pedals.
| Frame | E-Gravel Stealth Air Carbon, 386 EVO Pressfit bottom bracket, tapered head tube, internally routed cables (HHG), internally integrated, non-removable battery, 12 x 142 mm rear axle, designed for single or double drivetrains, compatible with flat-mount brakes, speed sensor integrated in the dropout. |
| Material | Carbon |
| Weight | approx. 14.4 kg |
| Fork | RockShox Rudy Ultimate, 40 mm travel, 12 x 100 mm Maxle Stealth, 45 mm offset |
| Manufacturer shift group | Sram |
| Rear derailleur | SRAM X1 Eagle AXS, Overload Clutch, Cage Lock, 1x12-speed |
| Number of gears | 1 x 12 |
| Crank handle | SRAM Rival 1 GLS Wide, size S: 170 mm, size M: 170 mm, size ML: 172.5 mm, size L: 172.5 mm, size XL: 175 mm |
| Cassette | SRAM XG-1275, 10-52T, 12-speed |
| Pedals included in the scope of delivery | nein |
| Gear lever | SRAM Rival Etap AXS 12-speed, Single Click |
| Rims | Mavic Allroad Disc, UST, 25 mm inner width, hookless, Infinity hubs, 24 spokes front, 28 spokes rear |
| Hubs | front: Mavic, 12 x 100 mm, IS 6-hole, rear: Mahle X20 Drive Unit, MS freehub |
| Wheel size | 28 Zoll |
| Tyres | Maxxis Rambler 700 x 45, tubeless ready, dual rubber compound, EXO Protection, 120 TPI, folding bead |
| Brakes | SRAM Rival Etap AXS, two-piece brake caliper, one-piece 160 mm IS 6-hole centreline brake disc, organic brake pad with steel backplate |
| Handlebars | ONOFF S9 GR CARBON 16° handlebar flare. Widths size S: 440 mm, size M: 440 mm, size L: 460 mm, size XL: 460 mm |
| Seat post | RockShox Reverb XPLR AXS 75 mm, wireless, 27.2 x 400 mm telescopic seatpost |
| Saddle | FIZIK Terra Argo X7 150 mm |
| Stem | ONOFF S3 GR 6061-T6 aluminium, 31.8 mm handlebar diameter, angle: -7°, length: size S: 60 mm, size M: 70 mm, size L: 80 mm, size XL: 90 mm |
| Engine | Mahle X20 drive 23 Nm |
| Display | Pulsar One Wireless |
| Battery | Mahle X20 IX350Wh |
Log in
Safety information for bicycles, e-bikes and children's bicycles
The safe and long-term use of bicycles, e-bikes and children's bicycles requires careful checks, regular maintenance and proper handling. These instructions provide you with practical recommendations for safe use and should be taken into account in conjunction with the operating instructions of the respective manufacturer.
1. Safety checks before riding
The following checks should be carried out before every journey:
Brakes and steering: Test the functionality of the brakes and ensure that the steering is smooth and stable.
Tyres and wheels: Check that the tyres are correctly inflated and that the wheels and quick-release skewers are secure.
Fastenings: Check that attachments such as mudguards, pannier racks, saddle and pedals are securely fastened.
Accessories and load: Make sure that luggage and accessories are correctly fitted and that the permitted load capacity is not exceeded.
2. Technical safety and authorised use
Component inspection: Regularly inspect safety-relevant components such as the frame, fork, handlebars, seat post and brakes for damage. Do not use the bike if there are visible defects.
Maximum load capacity: Observe the weight limits for the total weight (bike, rider, payload and trailer if applicable). The details can be found in the manufacturer's information.
Proper use: Only use the bike or e-bike within the scope of the intended use category. Improper use leads to safety risks.
Accessories and modifications: Only use approved accessories such as child seats or trailers and do not make any unauthorised modifications, especially to the drive system of e-bikes.
3. Special instructions for e-bikes
Battery and charging process:
Only use batteries and chargers approved by the manufacturer.
Charge the battery in a safe place and in accordance with the temperature specifications.
Remove the battery before transporting the e-bike.
Electric assistance:
Familiarise yourself with the assistance modes and the pushing aid. Test the e-bike in a safe environment first, especially with different loads or difficult ground conditions.
Running in the disc brakes:
Run in new brakes before your first big ride to ensure optimum braking performance.
Transport specifications:
Observe the manufacturer's instructions and legal regulations when transporting.
Component manuals:
For detailed information on e-bike systems from drive component manufacturers, find help here:
For Fazua motors:
https://fazua.com/de/support/help-center/knowledge-base/fazua-app/
For Bosch motors:
https://help.bosch-ebike.com/de/help-center#wss-manuals
For Shimano motors:
https://lifestylebike.shimano.com/de/support/
4. Special safety rules for children's bikes
Duty of supervision: Children may only use bicycles under the supervision of a responsible person.
Appropriate size and equipment: Make sure that the bike is age-appropriate and that all safety devices (e.g. brakes, reflectors, chain guard) are intact.
Loading and accessories: Attach child seats and pannier racks securely and ensure that the load capacity is not exceeded.
5. Care and maintenance
Cleaning: Use a soft cloth and mild cleaning agents. Avoid high-pressure cleaners to prevent damage to electrical and mechanical components.
Regular inspections: Schedule regular maintenance at a qualified specialist company to check for wear and ensure safety.
Spare parts: Only use original or approved spare parts to maintain the functionality of the bike.
6. Behaviour after the ride
Documenting damage: In the event of recognisable damage or malfunctions, the bike must not be used any further. Have it checked by a specialised company.
Avoid hot components: Avoid contact with heated components such as brake discs or drive units to prevent burns.
Final notes
This safety information provides you with a comprehensive overview for the safe use of bicycles, e-bikes and children's bicycles. Always observe the operating instructions of the respective manufacturer and contact a specialist dealer if you have any questions. Safe and responsible handling not only ensures your safety, but also extends the service life of your bike.
